1.说明 Description:
工作温度 Operation temperature:-60--250℃
可耐电压 Withstand Voltage: 0.5mm 4000V
1.0mm 10000V
硅橡胶材料 (Silicone Rubber material)
Excellent stability and insulation properties, oil resistance and chemical corrosion resistance, good flexibility.
2.应用 Application:
Used in medical equipment, household appliances, aerospace, military industry, automobile manufacturing, electronic components, transformers, motors, etc.
3.订货资料 Order Reference:
Optional colors: black, milky white, transparent, special colors can be customized;
Specification available: Reference to specification table,special specification also can be ordered.
规格 | 内径 | 壁厚 | 包装(M/R) |
C1.0 | 1.0±0.1 | 0.5±0.1 | 300 |
Z1.5 | 1.5±0.1 | 0.5±0.1 | 300 |
C2.0 | 2.0±0.1 | 0.5±0.1 | 300 |
Z2.5 | 2.5±0.2 | 0.5±0.1 | 300 |
C3.0 | 3.0±0.2 | 0.5±0.1 | 300 |
C3.5 | 3.5±0.2 | 0.5±0.1 | 300 |
Z4.0 | 4.0±0.2 | 0.5±0.1 | 200 |
C5.0 | 5.0±0.2 | 0.5±0.1 | 200 |
Z6.0 | 6.0±0.3 | 0.5±0.1 | 200 |
C7.0 | 7.0±0.3 | 1.00±0.2 | 200 |
Z8.0 | 8.0±0.3 | 1.00±0.2 | 100 |
C9.0 | 9.0±0.3 | 1.00±0.2 | 100 |
Z10.0 | 10.0±0.3 | 1.00±0.2 | 100 |
C12.0 | 12.0±0.3 | 1.00±0.2 | 100 |
C14.C | 14.0±0.3 | 1.00±0.2 | 100 |
C15.0 | 15.0±0.3 | 1.00±0.2 | 100 |
